What is the Danfoss 90308-085400-0?

Danfoss HOSE FTG, 4T/08, US/08, CS, STR, manufacturer part number 90308-085400-0. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

EAN/UPC639789304698
A dimension IN3.160
A dimension MM80.300
Angle shapeStraight
BrandSynflex by Danfoss
Compatible hose ID IN0.500
Compatible hose ID MM12.700
Compatible hoses37AL, 30CT (Size dependent), 3130, 3440 (Size dependent), 3580, 3630 (Size dependent), 3740 (Size dependent), 3800 (Size dependent), 3R30
Compatible tube OD IN0.50
Compatible tube OD MM12.700
Construction StyleCrimp
End size 1-12
End type 1Female 37/45 universal swivel
Finish platingZinc plating
Hex size 1 IN0.875
Hex size 1 MM22.000
Hex size 2 IN0.938
Hex size 2 MM23.000
Hose cut off factor IN1.670
Hose cut off factor MM42.300
Hose size-8
Inside diameter IN0.390
Inside diameter MM9.900
Product height in0.880
Product height mm22.352
Product length in3.150
Product length mm80.010
Product materialCarbon steel
Product width in0.940
Product width mm23.876 mm
Thread sealantNo
Thread size 13/4-16 UNF
Tube OD 1 IN0.500
Tube OD 1 MM12.700
Working pressure max BAR276
Working pressure max PSI4000
Working temperature max C100
Working temperature max F212
Working temperature min C-40
Working temperature min F-40
