What is the Danfoss 627321?

Danfoss F3 CG 10 CBC DG 8C 20, F3CG10CBCDG8C20, manufacturer part number 627321. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Actuation Type	Solenoid operated
Adjustment range	35-140 bar (500-2000 psi)
Adjustment range head 1	35-140 bar (500-2000 psi)
Adjustment range head 2	8.5-70 bar (125-1000 psi)
Adjustment range head 3	35-140 bar (500-2000 psi)
Adjustment type	Screw with locknut
Brand	Vickers by Danfoss
Coil voltage	115 VAC 60 Hz
Design Series	20 Series
Electrical connection	Flying lead
Flow rate lpm	454.0
Flow rate USGPM	120.0
Fluid Cleanliness	19/17/14 Micron
Fluid compatibility	Phosphate esters
Hi-vent spring	No
Indicator Light	No
Manual override	None
Maximum pressure BAR	210
Maximum pressure PSI	3000
Model Code 1	F3CG10CBCDG8C20
Performance	Standard
Product height in	9.870
Product height mm	250.698
Product length in	10.310
Product length mm	261.874
Product width in	5.030
Product width mm	127.762
Seal material	Fluorocarbon
Size	Size 10
Special feature	None
Stage	Two stage
Valve Mount Type	Subplate/manifold mounted
Valve type	Relief valve
Working temperature max C	70
Working temperature max F	158
Working temperature min C	-20
Working temperature min F	-4
