Danfoss 590
Cplng, 500 SERIES PLUG, STEEL
- MPN
- 590
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Danfoss 590?
Danfoss Cplng, 500 SERIES PLUG, STEEL, manufacturer part number 590. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| EAN/UPC | 678146103840 |
| Angle shape | Straight |
| Body size | 1/2 |
| Brand | Danfoss |
| Burst pressure min bar | 138 |
| Burst pressure min psi | 2000 |
| Connection style | Manual connect |
| End type 1 | Female Push to Connect |
| End type 2 | Line/hose/tube |
| Finish plating | Nickel |
| Flow rate GPM | 538.00 |
| Flow rate LPM | 2036.55 |
| Fluid compatibility | Compressed air, Gases and liquids |
| Item type | Female half |
| Product height in | 1.190 |
| Product height mm | 30.226 |
| Product length in | 4.090 |
| Product length mm | 103.886 |
| Product material | Brass |
| Product width in | 1.190 |
| Product width mm | 30.226 mm |
| Safety locking mechanism | Sleeve lock |
| Seal material | Nitrile (NBR) |
| Sub brand | Hansen |
| Valve type | 1 way |
| Working pressure max psi | 500 |
| Working pressure max BAR | 34 |
| Working temperature max C | 121 |
| Working temperature max F | 250 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
