Danfoss 59

COUPLING,500,M,1/2,B,-6BARB

MPN: 59
Category: Danfoss Hansen® quick disconnect couplings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 59?

Danfoss COUPLING,500,M,1/2,B,-6BARB, manufacturer part number 59. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146042101
Angle shape	Straight
Body size	1/2
Burst pressure min bar	138
Burst pressure min psi	2000
Connection style	Manual connect
End type 1	Male push to connect
End type 2	Line/hose/tube
Finish plating	Zinc
Flow rate GPM	538.00
Flow rate LPM	2036.55
Fluid compatibility	Compressed air, Gases and liquids
Item type	Male half
Latch type	Push/pull
Product height in	0.690
Product height mm	17.526
Product length in	2.660
Product length mm	67.564
Product material	Carbon steel
Product width in	0.690
Product width mm	17.526 mm
Seal material	Nitrile (NBR)
Valve type	2 way
Working pressure max psi	500
Working pressure max BAR	34
Working temperature max C	121
Working temperature max F	250
Working temperature min C	-40
Working temperature min F	-40
