What is the Danfoss 5650-12-10S?

Danfoss Cplng, 5600 SERIES complete, manufacturer part number 5650-12-10S. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

EAN/UPC678146036650
Air inclusion max cc2.80
Air inclusion max in30.17
Angle shapeStraight
Body size5/8
BrandDanfoss
Burst pressure min bar827
Burst pressure min psi12000
Connection styleManual connect
End size 2-12
End type 1Female Push to Connect
End type 2Female Pipe (NPT)
Finish platingZinc
Flow rate GPM12.00
Flow rate LPM45.43
Fluid loss cc2.80000
Fluid loss in30.17100
Hex size 1 IN1.250
Hex size 1 MM31.750
Item typeComplete
Latch typePush/pull
Product length in4.450
Product materialCarbon steel
Seal materialNitrile (NBR)
Sub brandHansen
Valve type2 way
Working pressure max psi4000
Working pressure max BAR276
Working temperature max C121
Working temperature max F250
Working temperature min C-40
Working temperature min F-40

5650-12-10S: frequently asked questions

When can 5650-12-10S be shipped?

5650-12-10S is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 5650-12-10S in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 5650-12-10S and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 5650-12-10S, subject to availability and destination.
