Danfoss 4T6FJ5

HOSE FTG, 4T/05, JIC-F/06, CS, STR

MPN: 4T6FJ5
Category: Thermoplastic hydraulic hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 4T6FJ5?

Danfoss HOSE FTG, 4T/05, JIC-F/06, CS, STR, manufacturer part number 4T6FJ5. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	2.070
A dimension MM	52.600
Angle shape	Straight
Brand	Synflex Optimum by Danfoss
Compatible hose ID IN	0.310
Compatible hose ID MM	7.938
Construction Style	Crimp
End size 1	-6
End type 1	Female 37 degree swivel
Finish plating	Dura-Kote
Hex size 1 IN	0.669
Hex size 1 MM	17.000
Hex size 2 IN	0.669
Hex size 2 MM	17.000
Hose cut off factor IN	1.250
Hose cut off factor MM	31.700
Hose size	-5
Inside diameter IN	0.210
Inside diameter MM	5.300
Product height in	0.790
Product height mm	20.066
Product length in	2.070
Product length mm	52.578
Product material	Carbon steel
Product width in	0.790
Product width mm	20.066 mm
Thread sealant	No
Thread size 1	9/16-18 UNF
Working pressure max BAR	400
Working pressure max PSI	5800
