Danfoss 4T16DL8

HOSE FTG, 4T/08, DKOL/16, CS, STR

MPN: 4T16DL8
Category: Thermoplastic hydraulic hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 4T16DL8?

Danfoss HOSE FTG, 4T/08, DKOL/16, CS, STR, manufacturer part number 4T16DL8. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	2.350
A dimension MM	59.600
Angle shape	Straight
Compatible hose ID IN	0.500
Compatible hose ID MM	12.700
Construction Style	Crimp
End size 1	-16
End type 1	24 deg. DKO swivel light duty
Finish plating	Dura-Kote
Hex size 1 IN	1.259
Hex size 1 MM	32.000
Hose cut off factor IN	1.180
Hose cut off factor MM	29.900
Hose size	-8
Inside diameter IN	0.380
Inside diameter MM	9.600
Product height in	1.259
Product height mm	32.000
Product length in	2.362
Product length mm	60.000
Product material	Carbon steel
Product width in	1.259
Product width mm	32.000 mm
Seal material	Nitrile (NBR)
Thread sealant	No
Thread size 1	M26x1.5
Working pressure max BAR	165
Working pressure max PSI	2400
