Danfoss 20691-18-06Z

HOSE NIPPLE ASSY,2P/06,M60D-F/18,CS,90D

MPN: 20691-18-06Z
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 20691-18-06Z?

Danfoss HOSE NIPPLE ASSY,2P/06,M60D-F/18,CS,90D, manufacturer part number 20691-18-06Z. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	2.570
A dimension MM	65.300
Angle shape	90 Degree
Brand	Winner by Danfoss
Compatible hose ID IN	0.380
Compatible hose ID MM	9.500
Construction Style	Crimp
Drop dimension IN	1.690
Drop dimension MM	43.00
Finish plating	Zinc plating
Hex size 1 IN	0.950
Hex size 1 MM	24.130
Hex size 2 IN	0.945
Hex size 2 MM	24.003
Hose cut off factor IN	1.380
Hose cut off factor MM	35.300
Hose size	-6
Inside diameter IN	0.280
Inside diameter MM	7.000
Product height in	2.236
Product height mm	56.794
Product length in	3.116
Product length mm	79.146
Product material	Carbon steel
Product width in	0.940
Product width mm	23.876
Series	Winner 2-Piece
Thread sealant	No
Thread size 1	M18x1.5

20691-18-06Z: frequently asked questions

When can 20691-18-06Z be shipped?

20691-18-06Z is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 20691-18-06Z in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 20691-18-06Z and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 20691-18-06Z, subject to availability and destination.
