Danfoss 1G20DS12

HOSE NIPPLE ASSY,1G/12,DKOH-B/20,CS,STR

MPN: 1G20DS12
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1G20DS12?

Danfoss HOSE NIPPLE ASSY,1G/12,DKOH-B/20,CS,STR, manufacturer part number 1G20DS12. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	2.830
A dimension MM	72.000
Angle shape	Straight
Brand	Aeroquip by Danfoss
Compatible hose ID IN	0.750
Compatible hose ID MM	19.000
Construction Style	Crimp
End connection torque	125-140 lb-ft(170-190 Nm)
End size 1	-20
End Type 1	24 deg. DKO swivel heavy duty
Finish plating	Dura-Kote
Hex size 1 IN	1.811
Hex size 1 MM	46.000
Hose cut off factor IN	1.630
Hose cut off factor MM	41.600
Hose size	-12
Inside diameter IN	0.610
Inside diameter MM	15.500
Product height in	2.091
Product height mm	53.109
Product length in	2.835
Product length mm	72.001
Product material	Carbon steel
Product width in	2.091
Product width mm	53.109
Proposition 65	Cancer and Reproductive Harm
Series	OTC
Thread sealant	No
Thread size 1	M36x2
Working pressure max BAR	172.00
Working pressure max PSI	2500.00
Working temperature max C	150
Working temperature max F	302
Working temperature min C	-40
Working temperature min F	-40
