Danfoss 1G10FSA10

HOSE FTG, 1G/10, FS/10, CS, 45D

MPN: 1G10FSA10
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1G10FSA10?

Danfoss HOSE FTG, 1G/10, FS/10, CS, 45D, manufacturer part number 1G10FSA10. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	2.850
A dimension MM	72.500
Angle shape	45 Degree
Brand	Aeroquip by Danfoss
Compatible hose ID IN	0.620
Compatible hose ID MM	15.900
Construction Style	Crimp
Drop dimension IN	0.640
Drop dimension MM	16.30
End size 1	-10
End Type 1	Female 45 degree swivel
Finish plating	Dura-Kote
Hex size 1 IN	1.063
Hex size 1 MM	27.000
Hose cut off factor IN	1.700
Hose cut off factor MM	43.100
Hose size	-10
Inside diameter IN	0.500
Inside diameter MM	12.800
Product height in	1.754
Product height mm	44.539
Product length in	3.910
Product length mm	99.301
Product material	Carbon steel
Product width in	1.227
Product width mm	31.171
Proposition 65	Cancer and Reproductive Harm
Series	OTC
Thread sealant	No
Thread size 1	7/8-14 UNF
Working temperature max C	150
Working temperature max F	302
Working temperature min C	-40
Working temperature min F	-40
