Danfoss 1BA6FJ6

HOSE NIPPLE ASSY,4S/06,JIC-F/06,CS,STR

MPN: 1BA6FJ6
Category: Spiral hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1BA6FJ6?

Danfoss HOSE NIPPLE ASSY,4S/06,JIC-F/06,CS,STR, manufacturer part number 1BA6FJ6. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146131133
A dimension IN	2.090
A dimension MM	53.086
Angle shape	Straight
Brand	Aeroquip by Danfoss
Compatible hose ID IN	0.380
Compatible hose ID MM	9.500
Construction Style	Crimp
End connection torque	18-20 lb-ft(24-27 Nm)
End size 1	-6
End type 1	Female 37 degree swivel
Finish plating	Zinc plating
Hex size 2 MM	17.500
Hose cut off factor IN	1.270
Hose cut off factor MM	32.200
Hose size	-6
Inside diameter IN	0.260
Inside diameter MM	6.700
Product height in	1.158
Product height mm	29.413
Product length in	2.120
Product length mm	53.848
Product material	Carbon steel
Product width in	1.158
Product width mm	29.413 mm
Series	B Series
Thread size 1	9/16-18 UNF
Working pressure max BAR	400
Working pressure max PSI	5800
Working temperature max C	149
Working temperature max F	300
Working temperature min C	-40
Working temperature min F	-40

1BA6FJ6: frequently asked questions

When can 1BA6FJ6 be shipped?

1BA6FJ6 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1BA6FJ6 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1BA6FJ6 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1BA6FJ6, subject to availability and destination.
