Danfoss 1A12DSB8

HOSE FTG, 1A/08, DKOH-B/12, CS, 90D

MPN: 1A12DSB8
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1A12DSB8?

Danfoss HOSE FTG, 1A/08, DKOH-B/12, CS, 90D, manufacturer part number 1A12DSB8. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146123503
A dimension IN	3.060
A dimension MM	77.700
Angle shape	90 Degree
Brand	Aeroquip by Danfoss
Compatible hose ID IN	0.500
Compatible hose ID MM	12.700
Compatible tube OD IN	0.75
Compatible tube OD MM	19.050
Construction Style	Crimp
Drop dimension IN	1.780
Drop dimension MM	45.30
End size 1	-12
End Type 1	24 deg. DKO swivel heavy duty
Finish plating	Dura-Kote
Hex size 1 IN	1.188
Hex size 1 MM	30.000
Hex size 2 IN	0.000
Hose cut off factor IN	1.890
Hose cut off factor MM	48.000
Hose size	-8
Inside diameter IN	0.350
Inside diameter MM	9.000
Product height in	2.390
Product height mm	60.706
Product length in	3.650
Product length mm	92.710
Product material	Carbon steel
Product width in	1.220
Product width mm	30.988
Proposition 65	Cancer and Reproductive Harm
Seal material	Nitrile (NBR)
Series	1A/Z Series
Thread sealant	No
Thread size 1	M24x1.5
Tube OD 1 IN	0.750
Tube OD 1 MM	19.050
Working pressure max BAR	330
Working pressure max PSI	4800
Working temperature max C	150
Working temperature max F	302
Working temperature min C	-40
Working temperature min F	-40
