Danfoss 1A10KF10

HOSE FTG, 1A/10, KSF/10, CS, STR

MPN: 1A10KF10
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1A10KF10?

Danfoss HOSE FTG, 1A/10, KSF/10, CS, STR, manufacturer part number 1A10KF10. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146123329
A dimension IN	2.840
A dimension MM	72.200
Angle shape	Straight
Brand	Aeroquip by Danfoss
Compatible hose ID IN	0.620
Compatible hose ID MM	15.900
Construction Style	Crimp
End size 1	-10
End Type 1	JIS Kawasaki, Komatsu swivel
Finish plating	Dura-Kote
Hex size 2 MM	30.000
Hose cut off factor IN	1.810
Hose cut off factor MM	46.000
Hose size	-10
Inside diameter IN	0.490
Inside diameter MM	12.400
Product height in	1.390
Product height mm	35.306
Product length in	2.970
Product length mm	75.438
Product material	Carbon steel
Product width in	1.390
Product width mm	35.306
Proposition 65	Cancer and Reproductive Harm
Series	1A/Z Series
Thread size 1	M24x1.5
Working temperature max C	150
Working temperature max F	302
Working temperature min C	-40
Working temperature min F	-40
