PVB32-VALVE-SAE-COMP-LSAB-PVLP

Name: PVB32-VALVE-SAE-COMP-LSAB-PVLP
Brand: Danfoss (Drives)
SKU: 11036631

MPN: 11036631 · Brand: Danfoss (Drives)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Compensated directional control valves
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can 11036631 be shipped?

11036631 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 11036631 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 11036631 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 11036631, subject to availability and destination.

Danfoss PVB32-VALVE-SAE-COMP-LSAB-PVLP, manufacturer part number 11036631. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A Side Interface	PVE32 # PVB32
B Side Interface	PVE32 # PVB32
Bottom Interface	Threaded Ports LS A/B
Certification	N/A
Compensation Type	Pre
Continous System Pressure	350
Dynamic Response (Damping)	Fixed Orifice Compensator
Ex Application	Ex h I/II
Left Interface	PVG32-Oring
LS Port Placement	Bottom A & B
LS Port Size	#5 - 1/2-20 UNF
LS Relief A	Individual LS
LS Relief B	Individual
LS-return or Ly-return	N/A
LY (LS Return) Facility	N/A
Marking	N/A
Maximum System Pressure Peaks	420
Meter Out A	N/A
Meter Out B	N/A
Module Type	Mid Module
Neutral Pressure Bleed-Off	N/A
P Gallery	Through
PO Check A	N/A
PO Check B	N/A
Port Connection Type	SAE [ISO 11926-1]
Port Size	#10 - 7/8-14 UNF
Primer	Passivation - Transparent
Product Category	Standard Part
Product type	N/A
Proposition 65	Cancer and Reproductive Harm
PVB Check Valve	Yes
Rated Flow	100
Right Interface	PVG32-Flat
Shock Valve Facility A	1 x PVLP63 Cavity
Shock Valve Facility B	1 x PVLP63 Cavity
Spool Interface	PVB32 LS Shuttle
T0 Facility	N/A
Tank Plugged	N/A
Tank Port Placement	N/A
Tank Port Size	N/A
Thermo/chock	N/A
Tie Rod Length	48
Tie Rod Type Left	Through Hole
Tie Rod Type Right	Through Hole
Top Interface	N/A
Valve Family	PVG16-48
Width	48
Work Module Type	PVB32 - flow up to 125 l/min
