Danfoss 11036623

TANDEM=GEAR PUMP GR3+GEAR PUMP GR2

MPN: 11036623
Category: GearMe modular two stage

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11036623?

Danfoss TANDEM=GEAR PUMP GR3+GEAR PUMP GR2, manufacturer part number 11036623. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A: Tandem Gr.3+2 family	SNW3NN + SNP2NN
B: 1st stage displacement	Displacement 22cc
C: 2nd stage displacement	Displacement 11cc
D: Rotation	Right rotation
E: Project version	With intermediate flange
F: Mounting flange	Flange with pilot D.50.8 and 4 holes for bolts (98,4x128,1)
G: Drive gear	Taper 1:8 - M14 x 1,5 - Key = 4 ; rear spline DIN 5482 22 x 19 L=16,5 CO41-CO42
H: Rear cover	Standard Cover for pump
I: 1st stage inlet size	20x3/4 GAS
J: 1st stage outlet size	20x3/4 GAS
K: 1st stage ports position	Standard from catalogue
L: 2nd stage inlet size	3/4 GAS
M: 2nd stage outlet size	1/2 GAS
N: 2nd stage ports position	Standard from catalogue
O-Ring, Inside Diameter	Slash
O: Seals	Standard seal
OC DELIMITER (-)	-
P: Screws	Standard screws
Proposition 65	Cancer and Reproductive Harm
Q: Valve setting	without setting
R: Mark type	Std Sauer Danfoss Marking
S: Mark position	Position Marking standard
Slash separator	Slash
