Danfoss 11036629

PVB Basic module w.SAE thread

MPN: 11036629
Category: Compensated directional control valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 11036629?

Danfoss PVB Basic module w.SAE thread, manufacturer part number 11036629. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A Side Interface	PVE32 # PVB32
B Side Interface	PVE32 # PVB32
Bottom Interface	N/A
Certification	N/A
Compensation Type	Pre
Continous System Pressure	350
Dynamic Response (Damping)	Fixed Orifice Compensator
Ex Application	Ex h I/II
Left Interface	PVG32-Oring
LS Port Placement	N/A
LS Port Size	N/A
LS Relief A	N/A
LS Relief B	N/A
LS-return or Ly-return	N/A
LY (LS Return) Facility	N/A
Marking	N/A
Maximum System Pressure Peaks	420
Meter Out A	N/A
Meter Out B	N/A
Module Type	Mid Module
Neutral Pressure Bleed-Off	N/A
P Gallery	Through
PO Check A	N/A
PO Check B	N/A
Port Connection Type	SAE [ISO 11926-1]
Port Size	#10 - 7/8-14 UNF
Primer	Passivation - Transparent
Product Category	Standard Part
Product type	N/A
Proposition 65	Cancer and Reproductive Harm
PVB Check Valve	Yes
Rated Flow	100
Right Interface	PVG32-Flat
Shock Valve Facility A	N/A
Shock Valve Facility B	N/A
Spool Interface	PVB32
T0 Facility	N/A
Tank Plugged	N/A
Tank Port Placement	N/A
Tank Port Size	N/A
Thermo/chock	N/A
Tie Rod Length	48
Tie Rod Type Left	Through Hole
Tie Rod Type Right	Through Hole
Top Interface	Threaded Ports
Valve Family	PVG16-48
Width	48
Work Module Type	PVB32 - flow up to 125 l/min
