What is the Danfoss 02-393680?

Danfoss DG4V-3-2A-M-FPM4WL-H7-60-EN623, DG4V32AMFPM4WLH760EN623, manufacturer part number 02-393680. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

Actuation TypeSolenoid operated
BrandVickers by Danfoss
Coil Rating24 VDC
Design Series60 Series
Electrical Connection4-Pin Brad Harrison connector
Energ Time45-28 ms
Flow rate upto GPM21.0
Flow rate upto LPM80.0
Fluid Cleanliness19/17/14 micron
Fluid compatibilityPetroleum oils
Indicator LightYes
InterfaceISO4401-03
Manual overridePlain
Model Code 1DG4V32AMFPM4WLH760EN623
PerformanceHigh performance
Power Consumption30 watt
Pressure rating BAR350
Pressure rating PSI5000
Product height in3.420
Product length in5.750
Product length mm146.050
Product width in1.800
Product width mm45.72
Seal typeWATER GLYCOL
Solenoid Energising IDStandard as per ANSI B93 9
Special featuresWired to automotive standard wiring scheme, terminal strip and push in lights
Spool Position MonitorNo
Spool TypeSpool 2
Spring ArrangementSpring offset end to end
StageSingle stage
Surge Suppr DamperNo
Tank port rating BAR210.0
Tank port rating PSI3000
Valve Mount TypeSubplate/manifold mounted
Valve typeDirectional control valve
Working temp max C70
Working temp max F158
Working temp min C-20
Working temp min F-4
