B&R ETAL210.1030-1

System offers you a wide range of options…

MPN: ETAL210.1030-1

Price and lead time confirmed within 1 business day

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

What is the B&R ETAL210.1030-1?

System ETAL210.1030-1 offers you a wide range of options from entry-level programming to more complex programming processes and even includes HMI. With other products from the ETA light system portfolio, the range of functions can be easily adapted and expanded to meet training needs.ETAL210.1030-1 - ETA light system control technology X20CP1382Enables extensive control tasksIntegrated HMI with VNC server or web serverIntegrated FTP and web serverClosed-loop control and mathematical functionsData recording on mass storage deviceWeb-based system diagnosticsI/O channels integrated in the deviceModular with other ETA light systems via POWERLINKCompact dimensions

Specifications

Input voltage	24 VDC -15% / +20%
B&R ID code	0xEADE
Power consumption	7.5 W
Reverse polarity protection	Yes
CE	Yes
Connection	Low voltage female connector 5.5 mm / 2.1 mm (0TP650.07)
Width	300 mm
Height	230 mm
Depth	90 mm
Weight	1.2 kg
Content of delivery	This product contains the following materials: ETAL100.0200-1 X20CP1382 ETAL100.3200-1F For details and additional technical data, see the data sheets for the individual products.
