B&R 1TGMPTWEET.20-01

Configuring state and command queries per SMS text message

MPN: 1TGMPTWEET.20-01
Category: Technology Guard

Price and lead time confirmed within 1 business day

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

Have spare B&R parts? We buy surplus →

What is the B&R 1TGMPTWEET.20-01?

Configuring state and command queries per SMS text message

Alarm notifications

mapp Tweet makes it possible to transmit messages directly from the machine. This allows service technicians to be informed of emergencies involving the machine via SMS text message. Quick responses to critical situations are possible via a direct connection to mapp AlarmX. Functional scope:

The information to be sent via SMS text message or the commands being processed by the machine are defined when the component is set up. This allows certain alarms to be defined in mapp AlarmX that will send an SMS text message when triggered. The time period in which the recipient must respond can be defined. If no response is received, the message is automatically forwarded to the next defined contact. SMS communication also works in the other direction. The state of a machine can be queried per SMS text message, for example, or a different reaction triggered. SMS text messages can be sent or received either via the B&R SiteManager or another modem that uses the AT command set.

Specifications

General information

System requirements – Automation Studio	4.3.3 or later
System requirements – Automation Runtime	B4.34 or later
System requirements – mapp Technology Package	mapp Services
Certifications – CRA (Cyber Resilience Act)	In preparation
Basic package license	1TGMPSRV.00-01
Behavior if license missing	License violation indicated by red blinking LED

Accessories

Required accessories (order separately)

1TGMPSRV.00-01

Technology Guard — Creating alarm, user and recipe management; Visual display of alarm, user and recipe management; Modifying the hardware configuration at ru…

Optional accessories (7)

X20CMR111	Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po…
X20CMR100	Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po…
X20CMR011	Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po…
X20cCMR011	Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po…
0TGF016.01	Technology Guard — Technology Guard (MSD) with integrated flash drive, 16 GB (MLC)
0TG1000.02	Technology Guard — Technology Guard (HID)
0TG1000.01	Technology Guard — Technology Guard (MSD)

Downloads & documentation

Official documents from B&R, downloaded directly from the manufacturer.

Certificates (1)

EULA (End User License Agreement) - AS, AR & mapp TechnologyPDF · 317 KB · 1.20 (08/12/2025) - EN
