Bosch Rexroth 3842547713

BASE UNIT 90+ AL CONNECT DIR.

MPN: 3842547713
Category: Drive and return unit AL

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Bosch Rexroth parts? We buy surplus →

What is the Bosch Rexroth 3842547713?

Base unit VA AL, VFplus [90]

Base unit connection drive + drive kit + active or passive bridge = a complete connection drive

Reduced noise emission due to slide rails guided in the connection drive

Installation of the drive kit possible on the right/left (motor, coupling, flange)

Drive of a parallel conveyor section or bridge using a hexagonal hollow shaft integrated as standard

Ball bearing made of non-rusting steel (1.4301), with seal on both sides and FDA-compliant grease filling

Side elements with slot to attach holders for lateral guides, or similar

Specifications

Size [b] [mm]	90
Scope of delivery	Incl. fastening material
Delivery information	Fully assembled
Material information	Ball bearing: Non-rusting steel 1.4301/FDA; Chain guide: PA; Chain wheel: PA; Connector: Steel, galvanized; Hexagonal shaft up to size 160: PA, from size 160: Non-rusting steel 1.4301 + PA; Housing: Diecast aluminum, powder-coated
Actual chain length [m]	1,51
Effective sliding rail length [m]	4x 0,2
Required accessories	Active bridge or passive bridge; Drive kit; Slide rail: Length calculation
Weight [kg]	10.32

3842547713: frequently asked questions

When can 3842547713 be shipped?

3842547713 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 3842547713 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 3842547713 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3842547713, subject to availability and destination.
