Home / Bosch Rexroth / Damper TS 5 / Bosch Rexroth 3842545128

Bosch Rexroth

Bosch Rexroth 3842545128

DAMPER DA 5/200

MPN: 3842545128
Category: Damper TS 5

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Bosch Rexroth parts? We buy surplus →

What is the Bosch Rexroth 3842545128?

DA 5/200 dampers

Damped stopping of an accumulating workpiece pallet during infeeding

Damping steplessly adjustable (DA 5/200, DA /1000 self-adjusting)

For the workpiece pallet system loads, refer to the technical data

The damper is extended pneumatically into the damping position (infeeding of the workpiece pallet to the main section) and is pushed into the end position by the infeeding workpiece pallet. A workpiece pallet can only move onto the main section if the damper is in the end position

Compressed air connection: 5 ... 6 bar

Specifications

Packaging unit	Set
required compressed air connection [pmax] [bar]	6
required compressed air connection [pmin] [bar]	5
Nominal speed [vN]	12 m/min; 15 m/min; 18 m/min; 9 m/min
Workpiece pallet total weight [mG] [kg]	280; 140; 240; 280
Pneumatic straight connection [Ø] [mm]	6
Scope of delivery	Incl. fastening material for installation on conveyor section; Push in air connection ø 6 mm
Delivery information	Not assembled
Recommended accessories	Lateral guide cover
Weight [kg]	5.4
