Beckhoff IE2512
Extension Box, 2-channel PWM output, 24 V DC, 2.5 A, M12
- MPN
- IE2512
- Category
- Digital-Ausgang IE2xxx
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the Beckhoff IE2512?
The outputs of the IE2512 module provide a pulse width modulated version of a binary signal. The keying ratio is prescribed by a 10 bit value from the automation unit. The output is protected against overload and short circuit. In addition to the PWM
Specifications
Specifications
| Number of outputs | 2 |
| Output connections | M12, screw type |
| Load type | ohmic, inductive |
| Nominal output voltage | 24 V DC (-15%/+20%) |
| Max. output current | 2.5 A per channel, individually short-circuit proof |
| Current consumption from US (without sensor current) | 25 mA |
| Up/down channel | 24 V DC, 0.5 A, short-circuit proof |
| Base frequency | 8 Hz…40 kHz, default: 250 Hz |
| Duty factor | 0…100% (pulse duration TON > 750 ns, pause duration TOFF > 500 ns) |
| Resolution | max. 10 bit |
| Freewheeling diode (output) | yes |
| Power supply connection | feed: 1 x M8 male socket, 4-pin, a-coded; downstream connection: 1 x M8 female socket, 4-pin, a-coded |
| Bit width in the process image | 48 inputs/outputs: 2 x 16 bit data, 2 x 8 bit control/status |
| Electrical isolation | channels/control voltage: no, between the channels: no, control voltage/fieldbus: yes, via IP-Link |
| Operating temperature | 0…55°C |
| Storage temperature | -25…+85°C |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP65/66/67 (conforms to EN 60529)/variable |
| Approvals/markings | CE, UL |
| Dimensions (W x H x D) | 30 mm x 126 mm x 26.5 mm |
| Material | PA6 (polyamide) |
| Installation | 2 fixing holes 3.5 mm diameter for M3 |
