EtherCAT IP core for Microchip® FPGAs

Name: Beckhoff ET1820, ET1821, ET1822 – EtherCAT IP core for Microchip® FPGAs
Brand: Beckhoff
SKU: ET1820, ET1821, ET1822

MPN: ET1820, ET1821, ET1822 · Brand: Beckhoff

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	ELxxxx, ETxxxx, FBxxxx \| Hardware
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can ET1820, ET1821, ET1822 be shipped?

ET1820, ET1821, ET1822 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up ET1820, ET1821, ET1822 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for ET1820, ET1821, ET1822 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for ET1820, ET1821, ET1822, subject to availability and destination.

The EtherCAT IP core enables the EtherCAT communication function and application-specific functions to be implemented on an FPGA (field programmable gate array, an integrated circuit containing programmable logical components). The EtherCAT functionality

Specifications

PHY interface	1…4 ports MII, 1…4 ports RGMII or 1…4 ports RMII
FMMUs	0…16
SYNC manager	0…16
DPRAM	0…60 KB
Distributed clocks	0…4 SYNC outputs, 0…4 latch inputs (32/64 bit)
Process data interfaces	PDI0: 32 bit digital I/O, SPI slave, 8/16/32 bit asynchrones µC-Interface, AMBA AXI4 interface. PDI1: 32 bit digital I/O, SPI slave, AMBA AXI4 interface. 64 bit general purpose I/O
