What is the Beckhoff ET1815, ET1816, ET1817?

The EtherCAT IP core enables the EtherCAT communication function and application-specific functions to be implemented on an FPGA (field programmable gate array, an integrated circuit containing programmable logical components). The EtherCAT functionality

Specifications

Specifications

PHY interface1…4 ports MII, 1…4 ports RGMII or 1…4 ports RMII
FMMUs0…16
SYNC manager0…16
DPRAM0…60 KB
Distributed clocks0…4 SYNC outputs, 0…4 latch inputs (32/64 bit)
Process data interfacesPDI0: 32 bit digital I/O, SPI slave, 8/16/32 bit asynchrones µC-Interface, AMBA AXI4 interface. PDI1: 32 bit digital I/O, SPI slave, AMBA AXI4 interface. 64 bit general purpose I/O
