ABB

ABB IDCRPM18204

20HP,1750,460V,FL1848,TEFC,F1,LSPM

MPN: IDCRPM18204
Category: RPM AC Inverter Duty

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare ABB parts? We buy surplus →

What is the ABB IDCRPM18204?

eXtreme Efficient RPMAC Motors 20 Hp 460 V (IDCRPM18204)

Specifications

Ordering

Catalog Number	IDCRPM18204
Brand / Label	Baldor-Reliance
Country or Territory of Origin	United States
Customs Tariff Number	85015220
Minimum Order Quantity	1 piece
Order Multiple	1 piece

Electrical

Ambient Temperature	40 °C
Duty Time	60 Min
Insulation Class	H
Number of Phases	3-phase
Service Factor	1.15
Type of Duty	Continuous
Starting of Motor	Full Load Start
Synchronous Speed (vsyn)	1800 r/min
Output Power	20 Hp

Mechanical

Drive End Flange Type	Non-Standard
Enclosure Type	TEFC
Frame Material	Explosed Laminations
Motor Frame Size	Fl1848Z
Motor Base Type	Foot Mounted
Mounting Position	F3
Brake Present	No

Dimensions

Product Net Height	0 in
Product Net Weight	225 lb
Product Net Width	0 in
Dimension Diagram	617511-001

Certificates and Declarations

Certification Agency	CCSA US, NEMA_PREMIUM
ETIM 7	EC001851 - Electric motor
