ABB ACQ580-01-059A-2+P918

LV AC wall-mounted drive for water and wastewater, 208 … 240 V ( )

MPN: ACQ580-01-059A-2+P918
Category: Wall-mounted drive for water and wastewater

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

What is the ABB ACQ580-01-059A-2+P918?

The ACQ580-01 drives deliver innovative pump features for the water and wastewater industry, securing energy efficient flow of water and wastewater in your pumping solutions. This robust and compact wall-mounted drive has built-in pump application functionality such as sensorless flow calculation, multipump control, level control, soft pipe fill, dry run protection, quick ramps and a solution for keeping the impeller of the pump clean. Usability is further enhanced with the intuitive Hand-Off-Auto control panel, the PC tool Drive composer and an optional Bluetooth® control panel. The built-in energy calculator visualizes the energy savings achieved with the use of the drive. The ACQ580-01 variant comes in IP21 enclosure as standard and can be installed on the wall. Also, IP55 and flange mounting units are available.

Specifications

Customs Tariff Number	85044080
HS Code	850440 -- ELECTRICAL MACHINERY AND EQUIPMENT AND PARTS THEREOF; SOUND RECORDERS AND REPRODUCERS, TELEVISION IMAGE AND SOUND RECORDERS AND REPRODUCERS, AND PARTS AND ACCESSORIES OF SUCH ARTICLES;Electrical transformers, static converters (for example, rectifiers) and inductors;Static converters
Invoice Description	ACQ580-01-059A-2, 230VAC, Pn 15HP, I2LD 46.2A, N1/IP21
Made To Order	No
Minimum Order Quantity	1 piece
Order Multiple	1 piece
Quote Only	No
Selling Unit of Measure	piece
Product Net Weight	26 lb
Product Net Depth / Length	9.01 in
Product Net Height	19.29 in
Product Net Width	7.99 in
Package Level 1 Units	1 carton
Number of Phases	3-phase
Degree of Protection	IP21
Enclosure Type NEMA	Type1
Frequency (f)	50/60 Hz
Frame Size	R3
Input Voltage (Uin)	208 … 240 V
Mounting Type	Wall-mounting
Apparent Power Output	24 kV·A
Efficiency Level	IE2
Standby Loss	15 W
Temperature Rating	Maximum 40 °C
WEEE Category	5. Small Equipment (No External Dimension More Than 50 cm)
UNSPSC	39122001
