What is the B&R 0TG 1000.02?

B&R 0TG 1000.02

Specifications

Short description

Accessories

Technology Guard for B&R license management

General information

Application memory – Size	241 bytes customized data
Application memory – Operation	Via library AsGuard
Application memory – Guaranteed erase/write cycles	Up to 10 million updates
Certifications – CE	Yes
Certifications – UKCA	Yes
Certifications – CRA (Cyber Resilience Act)	In preparation
Certifications – UL	cULus E115267; Industrial control equipment
Certifications – HazLoc	cULus HazLoc E180196; Industrial control equipment; for hazardous locations; Class I, Division 2, Groups ABCD, T4
Certifications – DNV	Temperature: B (0 to 55°C); Humidity: B (up to 100%); Vibration: A (0.7 g); EMC: B (bridge and open deck)
Certifications – CCS	Yes
Certifications – LR	ENV3
Certifications – KR	Yes
Certifications – ABS	Yes
Certifications – BV	EC31B ; Temperature: 5 - 55°C; Vibration: 0.7 g; EMC: Bridge and open deck
Note	Manufacturer ID: 0x064F; Product ID: 0x2AF9
Connection	High-speed USB 2.0 certified, 1.1 compatible
Coding	128-bit AES, SHA-256, 2048-bit RSA, 224-bit ECC
Data retention	10 years at room temperature
Data reliability	Licenses: Up to 10 million updates
MTBF	>3 million hours
Power supply	5 V
Power consumption	<20 mA (LEDs off); <60 mA (both LEDs on)

Ambient conditions

Temperature – Operation	-25 to 85°C
Relative humidity – Operation	5 to 95%, non-condensing

Mechanical properties

Dimensions – Width	12 mm
Dimensions – Length	16.7 mm
Dimensions – Height	4.5 mm
