B&R 3DO479.6 Used Rev. G0 – 2005 digital output module, 16 transistor outputs 24 VDC
Request a Quote
Quick facts
| Availability | In stock — 2 available |
| Category | Digital I/O Modules |
| Warranty | 3-month |
| Weight | 0.3 kg |
| Country of origin | AT |
| Datasheet | Manufacturer datasheet ↗ |
Shipping & availability
When can 3DO479.6 be shipped?
3DO479.6 is in stock and typically ships within 1 business day via UPS, DHL or FedEx, worldwide.
Can I pick up 3DO479.6 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — alongside standard UPS, DHL and FedEx shipping, express (next-day) delivery is available at checkout for in-stock items like 3DO479.6.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3DO479.6, subject to availability and destination.
2005 digital output module, 16 transistor outputs 24 VDC, 0.5 A, 2 electrically isolated output groups, order 1x terminal block TB170 separately!
Accessories
Specifications
Short description
| I/O module | 16 digital outputs 24 VDC in 2 groups |
General information
| Diagnostics – Outputs | Yes, using LED status indicator |
| Diagnostics – Operating state of outputs | Yes, using LED status indicator |
| Power consumption – 24 VDC | - |
| Power consumption – 5 VDC | 1.0 W |
| Power consumption – Total | 1.0 W |
| Power consumption – External 24 V | 4.0 W |
| Electrical isolation – Group - Group | Yes |
| Electrical isolation – Channel - Channel | No (same group) |
| Electrical isolation – Channel - PLC | Yes |
| Certifications – CE | Yes |
| Certifications – UKCA | Yes |
| Certifications – UL | cULus E115267; Industrial control equipment |
| Status indicators | I/O function per channel, operating state of the outputs |
Digital outputs
| Nominal voltage | 24 VDC |
| Nominal output current | 0.5 A |
| Total nominal current | 8.0 A |
| Output circuit | Source |
| Output protection | Thermal shutdown in the event of overcurrent or short circuit, integrated protection for switching inductive loads, reverse polarity protection of the output power supply |
| Group rated voltage | 4.0 A |
Operating conditions
| Degree of protection per EN 60529 | IP20 |
Ambient conditions
| Temperature – Operation | 0 to 60°C |
| Temperature – Storage | -25 to 70°C |
| Relative humidity – Operation | 5 to 95% |
Mechanical properties
| Dimensions – Width | System 2005 single-width |
| Can be installed on – Base unit | Yes |
| Can be installed on – Expansion unit | Yes |
| Note | Order 1x terminal block TB170 separately. |
Downloads & documentation
Official documents from B&R, downloaded directly from the manufacturer.
Data sheets & manuals
| Datasheet 3DO479.6 | PDF · 465 KB · 4.12 (11/17/2009) - EN |
