Planetary gearboxes with output flange 8GF Parts

Showing 97–120 of 125 parts

Compare Planetary gearboxes with output flange 8GF

Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.

MPNGear ratio iIdle torque [Nm] at 20°C and 3000 rpmMax. average drive speed n 1N50% [rpm] at 50% T 2N and S1Max. average drive speed n 1N100% [rpm] at 100% T 2N and S1Moment of inertia J 1 [kgcm 2]
8GF70-200hh004klmm426.8575070045.173
8GF70-200hh005klmm518.0595085036.268
8GF70-200hh007klmm710.71250115028.706
8GF70-200hh010klmm106.651700155024.718
8GF70-200hh016klmm167.951550140010.876
8GF70-200hh020klmm205.5190017009.208
8GF70-200hh025klmm254.85205019008.852
8GF70-200hh035klmm353.05265024507.652
8GF70-200hh040klmm402.3300028007.084
8GF70-200hh050klmm502.1300030006.995
8GF70-200hh070klmm701.9300030006.922
8GF70-200hh100klmm1001.8300030006.88
8GF60-064hh007klmm70.4320028000.24
8GF60-090hh007klmm70.75300025000.7
8GF60-110hh007klmm71.65235019502.29
8GF60-140hh007klmm73.9140011008.7
8GF60-200hh004klmm425.7550040056.66
8GF60-200hh005klmm517.160045043.67
8GF60-200hh008klmm87.9100080029.1
8GF60-200hh010klmm105.951300115025.8
8GF60-200hh016klmm167.8110080042.55
8GF60-200hh020klmm205.25135095040.78
8GF60-200hh025klmm254.71550110029.7
8GF60-200hh032klmm322.752000140039.8

Common to all listed parts

Min. operating temperature B Tempmin [°C]-25
Max. operating temperature B Tempmax [°C]90
