Industrial hose and fittings Parts
























Compare Industrial hose and fittings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | EAN/UPC | Bend radius min (inch) | Bend radius min (mm) | Inside diameter (inch) | Inside diameter (mm) |
|---|---|---|---|---|---|
| H055424-150 | 639789270399 | 8.000 | 203.200 | 1.50 | 38.10 |
| H055420-100 | 810903032035 | 7.000 | 177.800 | 1.25 | 31.80 |
| H055420 | 810903031809 | 7.000 | 177.800 | 1.25 | 31.80 |
| H055416-150 | 639789298362 | 6.000 | 152.400 | 1.00 | 25.40 |
| H055416 | 639789275059 | 6.000 | 152.400 | 1.00 | 25.40 |
| H055412-100 | — | 5.000 | 127.000 | 0.75 | 19.00 |
| H055412 | 810903032400 | 5.000 | 127.000 | 0.75 | 19.00 |
| H052364PR-150 | 639789270306 | 15.000 | 381.000 | 4.00 | 101.60 |
| H052364PR-100 | 639789275011 | 15.000 | 381.000 | 4.00 | 101.60 |
| H052364PR | 639789275004 | 15.000 | 381.000 | 4.00 | 101.60 |
| H052364GN-150 | 639789355331 | 15.000 | 381.000 | 4.00 | 101.60 |
| H052364GN-100 | 639789355324 | 15.000 | 381.000 | 4.00 | 101.60 |
| H052364GN | 639789355317 | 15.000 | 381.000 | 4.00 | 101.60 |
| H052348PR-150 | 639789265685 | 9.020 | 229.000 | 3.00 | 76.20 |
| H052348PR-100M20 | 639789355300 | 9.020 | 229.000 | 3.00 | 76.20 |
| H052348PR-100 | 639789275325 | 9.020 | 229.000 | 3.00 | 76.20 |
| H052348PR | 639789277800 | 9.020 | 229.000 | 3.00 | 76.20 |
| H052348GN-20 | 639789355294 | 9.020 | 229.000 | 3.00 | 76.20 |
| H052348GN-150 | 639789270337 | 9.020 | 229.000 | 3.00 | 76.20 |
| H052348GN-100 | 639789355287 | 9.020 | 229.000 | 3.00 | 76.20 |
| H052348GN | 639789275035 | 9.020 | 229.000 | 3.00 | 76.20 |
| H052348BU-150 | 639789270351 | 9.020 | 229.000 | 3.00 | 76.20 |
| H052340PR-150 | 639789270290 | 8.740 | 222.000 | 2.50 | 63.50 |
Common to all listed parts
| Abrasion resistance | Standard |
| Compliances | ASTM D380 |
| Conductivity | Conductive |
| Cover material | EPDM |
| Lay line style | Ink transfer |
| Tube material | UHMW |
| Vacuum rating (inHg) | 28 |
| Vacuum rating (mmHg) | 711.20 |
