Braided hose and fittings Parts
Compare Braided hose and fittings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Bend radius min (inch) | Product height in | Product height mm | Product width in | Product width mm |
|---|---|---|---|---|---|
| GH120-24 | 10.000 | 1.500 | 38.100 | 1.500 | 38.1 |
| GH120-20-14400 | 8.250 | 1.250 | 31.800 | 1.250 | 31.8 |
| GH120-20-12000 | 8.250 | 1.250 | 31.800 | 1.250 | 31.8 |
| GH120-20-06000 | 8.250 | 1.250 | 31.800 | 1.250 | 31.8 |
| GH120-20-04800 | 8.250 | 1.250 | 31.800 | 1.250 | 31.8 |
| GH120-20 | 8.250 | 1.250 | 31.800 | 1.250 | 31.8 |
| GH120-16R150 | 6.000 | 1.000 | 25.400 | 1.000 | 25.4 |
| GH120-16-13080 | 6.000 | 1.000 | 25.400 | 1.000 | 25.4 |
| GH120-16-06000 | 6.000 | 1.000 | 25.400 | 1.000 | 25.4 |
| GH120-16 | 6.000 | 1.000 | 25.400 | 1.000 | 25.4 |
| GH120-12R250 | 4.750 | 0.750 | 19.000 | 0.750 | 19 |
| GH120-12-13080 | 4.750 | 0.750 | 19.000 | 0.750 | 19 |
| GH120-12-06000 | 4.750 | 0.750 | 19.000 | 0.750 | 19 |
| GH120-12 | 4.750 | 0.750 | 19.000 | 0.750 | 19 |
| GH120-10R250 | 4.000 | 0.620 | 15.900 | 0.620 | 15.9 |
| GH120-10 | 4.000 | 0.620 | 15.900 | 0.620 | 15.9 |
| GC2542-10 | — | 1.360 | 34.544 | 1.180 | 29.972 |
| GA505-8 | 3.540 | 0.500 | 12.700 | 0.500 | 12.7 |
| GA505-6 | 2.760 | 0.380 | 9.500 | 0.380 | 9.5 |
| GA505-4 | 1.570 | 0.250 | 6.400 | 0.250 | 6.4 |
| GA505-12 | 5.910 | 0.750 | 19.000 | 0.750 | 19 |
| GA505-10 | 4.330 | 0.620 | 15.900 | 0.620 | 15.9 |
| GA17089-5 | — | 1.000 | 25.400 | 0.870 | 22.098 |
| GA17089-16 | — | 1.790 | 45.466 | 1.610 | 40.894 |
