3VA Molded Case Circuit Breakers up to 1600 A, IEC Parts
Compare 3VA Molded Case Circuit Breakers up to 1600 A, IEC
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | power loss [W] / maximum | Net Weight | operational current — at 55 °C | operational current — at 60 °C | adjustable response value setting current (Ir) / of the L-trip / with I2t characteristic — minimum |
|---|---|---|---|---|---|
| 3VA2216-6KQ32-0AA0 | 19.7 W | 2.268 kg | 160 A | 160 A | 64 A |
| 3VA2216-6JQ42-0AA0 | 19.7 W | 2.813 kg | 160 A | 160 A | 64 A |
| 3VA2125-6HL42-0AA0 | 0.6 W | 2.769 kg | 25 A | 25 A | 10 A |
| 3VA1140-4EE32-0AA0 | 10.8 W | 915 g | 39 A | 39 A | 28 A |
| 3VA1140-4ED46-0AA0 | 10.8 W | 1.275 kg | 39 A | 39 A | 40 A |
| 3VA1140-3GE42-0AA0 | 10.8 W | 1.211 kg | 39 A | 39 A | 28 A |
| 3VA1140-3GD46-0AA0 | 10.8 W | 1.301 kg | 39 A | 39 A | 40 A |
| 3VA1120-5EE42-0AA0 | 12 W | 1.198 kg | 20 A | 19 A | 14 A |
| 3VA1120-5EE36-0AA0 | 12 W | 990 g | 20 A | 19 A | 14 A |
| 3VA1120-3EF32-0AA0 | 12 W | 930 g | 20 A | 19 A | 14 A |
| 3VA1120-3EE46-0AA0 | 12 W | 1.279 kg | 20 A | 19 A | 14 A |
| 3VA1132-3EE42-0AA0 | 10.6 W | 1.195 kg | 31 A | 31 A | 22 A |
| 3VA1125-5GE42-0AA0 | 8.5 W | 1.254 kg | 24 A | 24 A | 17 A |
| 3VA1125-5GD46-0AA0 | 8.5 W | 1.318 kg | 24 A | 24 A | 25 A |
| 3VA1110-6MH36-0AA0 | 25 W | 964 g | 98 A | 96 A | — |
| 3VA1110-6MH32-0AA0 | 25 W | 945 g | 98 A | 96 A | — |
| 3VA1112-3ED16-0AA0 | 9.37 W | 425 g | 122 A | 120 A | 125 A |
| 3VA1120-4ED32-0AA0 | 12 W | 917 g | 20 A | 19 A | 20 A |
| 3VA1120-4ED26-0AA0 | 8 W | 0.687 kg | 20 A | 19 A | 20 A |
| 3VA1120-4ED22-0AA0 | 8 W | 659 g | 20 A | 19 A | 20 A |
| 3VA1120-3GF42-0AA0 | 12 W | 1.228 kg | 20 A | 19 A | 14 A |
| 3VA1120-3GE46-0AA0 | 12 W | 1.321 kg | 20 A | 19 A | 14 A |
| 3VA1112-3EE36-0AA0 | 28.1 W | 1.029 kg | 122 A | 120 A | 87 A |
| 3VA1102-6MG36-0AA0 | 1.5 W | 0.9 kg | 2 A | 2 A | — |
Common to all listed parts
| product designation | Molded case circuit breaker |
| product component — undervoltage release | No |
| product component — voltage trigger | No |
| product component — trip indicator | No |
| arrangement of electrical connectors / for main current circuit | Front terminal |
| number of CO contacts / for auxiliary contacts | 0 |
| protection class IP / on the front | IP40 |
| ambient temperature — during operation / minimum | -25 °C |
