Mitsubishi Low-voltage switchgear – Thermal Overload Relays Parts

Showing 49–72 of 136 parts
Mitsubishi Electric TH-T100KPSR – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T100KPSR

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T100SR – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T100SR

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T100FSKP – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T100FSKP

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T100FS – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T100FS

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T65KPSR – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T65KPSR

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T65SR – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T65SR

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T65CWFSKP – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T65CWFSKP

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T65FSKP – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T65FSKP

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T65CWFS – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T65CWFS

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T65FS – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T65FS

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T50BCKPSR – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T50BCKPSR

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T50KPSR – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T50KPSR

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T50BCSR – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T50BCSR

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T50SR – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T50SR

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T50BCFSKP – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T50BCFSKP

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T50FSKP – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T50FSKP

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T50BCFS – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T50BCFS

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T50FS – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T50FS

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T25BCKPSR – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T25BCKPSR

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T25KPSR – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T25KPSR

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T25BCSR – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T25BCSR

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T25SR – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T25SR

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T25BCFSKP – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T25BCFSKP

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T25FSKP – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T25FSKP

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Compare Mitsubishi Low-voltage switchgear – Thermal Overload Relays

Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.

MPNAdjustment Range of Setting Current [A]Heater Designation [A]: Category-1Heater Designation [A]: Category-2Combined Magnetic Contactor Frame: Category-1Terminal Screw Size: Main Circuit (Load Side)
TH-T100KPSR54 to 1006782T80,T100M6
TH-T100SR54 to 1006782T80,T100M6
TH-T100FSKP54 to 936782T80,T100M6
TH-T100FS54 to 936782T80,T100M6
TH-T65KPSR12 to 6515 to 54—T65,T80,T100M6
TH-T65SR12 to 6515 to 54—T65,T80,T100M6
TH-T65CWFSKP34 to 6542,54—T65,T80,T100M6
TH-T65FSKP34 to 6542,54—T65,T80,T100M6
TH-T65CWFS34 to 6542,54—T65,T80,T100M6
TH-T65FS34 to 6542,54—T65,T80,T100M6
TH-T50BCKPSR24 to 502935,42T35,T50M5
TH-T50KPSR24 to 502935,42T35,T50M5
TH-T50BCSR24 to 502935,42T35,T50M5
TH-T50SR24 to 502935,42T35,T50M5
TH-T50BCFSKP24 to 5029A35,42T35,T50M5
TH-T50FSKP24 to 5029A35,42T35,T50M5
TH-T50BCFS24 to 5029A35,42T35,T50M5
TH-T50FS24 to 5029A35,42T35,T50M5
TH-T25BCKPSR0.2 to 260.24 to 1522T21,T25,T35,T50M4
TH-T25KPSR0.2 to 260.24 to 1522T21,T25,T35,T50M4
TH-T25BCSR0.2 to 260.24 to 1522T21,T25,T35,T50M4
TH-T25SR0.2 to 260.24 to 1522T21,T25,T35,T50M4
TH-T25BCFSKP1.7 to 262.1 to 1522T21,T25,T35,T50M4
TH-T25FSKP1.7 to 262.1 to 1522T21,T25,T35,T50M4

Common to all listed parts

SeriesLow-voltage switchgear
Rated Insulation Voltage Ui [V]690
Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC24V2
Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC120V2
Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC240V1
Rated Operating Current [A]: AC Coil Load (Category AC-15) Break Contact: AC24V3
Rated Operating Current [A]: AC Coil Load (Category AC-15) Break Contact: AC120V3
Rated Operating Current [A]: AC Coil Load (Category AC-15) Break Contact: AC240V2
