Mitsubishi Low-voltage switchgear – Thermal Overload Relays Parts

Showing 121–136 of 136 parts
Mitsubishi Electric TH-T65CWKP – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T65CWKP

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T65KP – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T65KP

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T65CW – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T65CW

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T65 – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T65

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T50BCKP – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T50BCKP

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T50KP – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T50KP

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T50BC – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T50BC

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T50 – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T50

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T25BCKP – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T25BCKP

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T25KP – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T25KP

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T25BC – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T25BC

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T25 – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T25

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T18BCKP – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T18BCKP

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T18KP – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T18KP

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T18BC – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T18BC

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Mitsubishi Electric TH-T18 – Mitsubishi Low-voltage switchgear Thermal Overload Relay
Mitsubishi Electric
TH-T18

Mitsubishi Low-voltage switchgear Thermal Overload Relay

Compare Mitsubishi Low-voltage switchgear – Thermal Overload Relays

Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.

MPNAdjustment Range of Setting Current [A]Heater Designation [A]: Category-1Combined Magnetic Contactor Frame: Category-1Terminal Screw Size: Main Circuit (Load Side)Heater Designation [A]: Category-2
TH-T65CWKP12 to 6515 to 54T65,T80M6—
TH-T65KP12 to 6515 to 54T65,T80,T100M6—
TH-T65CW12 to 6515 to 54T65,T80M6—
TH-T6512 to 6515 to 54T65,T80,T100M6—
TH-T50BCKP24 to 5029T35,T50M535,42
TH-T50KP24 to 5029T35,T50M535,42
TH-T50BC24 to 5029T35,T50M535,42
TH-T5024 to 5029T35,T50M535,42
TH-T25BCKP0.2 to 260.24 to 15T21,T25,T35,T50M422
TH-T25KP0.2 to 260.24 to 15T21,T25,T35,T50M422
TH-T25BC0.2 to 260.24 to 15T21,T25,T35,T50M422
TH-T250.2 to 260.24 to 15T21,T25,T35,T50M422
TH-T18BCKP0.1 to 180.12 to 9T10,T12,T20M3.511
TH-T18KP0.1 to 180.12 to 9T10,T12,T20M3.511
TH-T18BC0.1 to 180.12 to 9T10,T12,T20M3.511
TH-T180.1 to 180.12 to 9T10,T12,T20M3.511

Common to all listed parts

SeriesLow-voltage switchgear
Product SpecificationStandard Type
Rated Insulation Voltage Ui [V]690
Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC24V2
Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC120V2
Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC240V1
Rated Operating Current [A]: DC Coil Load (Category AC-13) Make Contact: DC110V0.2
Rated Operating Current [A]: DC Coil Load (Category AC-13) Make Contact: DC220V0.1
