Mitsubishi Electric TH-T65FS

Mitsubishi Low-voltage switchgear Thermal Overload Relay

MPN
TH-T65FS
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric TH-T65FS?

The Mitsubishi Electric TH-T65FS is a thermal Overload Relay in the Low-voltage switchgear. Overload Protection Adjustment Range of Setting Current:34 to 65A 3-Pole 2-Element. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesLow-voltage switchgear
OutlineOverload Protection Adjustment Range of Setting Current:34 to 65A 3-Pole 2-Element

Specifications

Product SpecificationQuick Trip Type
Rated Insulation Voltage Ui [V]690
Elements2
Protection ModeOverload Protection
Adjustment Range of Setting Current [A]34 to 65
Tripping Class5
Heater Designation [A]: Category-142,54
Combined Magnetic Contactor Frame: Category-1T65,T80,T100
Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC24V2
Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC120V2
Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC240V1
Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC550V0.5
Rated Operating Current [A]: AC Coil Load (Category AC-15) Break Contact: AC24V3
Rated Operating Current [A]: AC Coil Load (Category AC-15) Break Contact: AC120V3
Rated Operating Current [A]: AC Coil Load (Category AC-15) Break Contact: AC240V2
Rated Operating Current [A]: AC Coil Load (Category AC-15) Break Contact: AC550V1
Rated Operating Current [A]: DC Coil Load (Category AC-13) Make Contact: DC24V1
Rated Operating Current [A]: DC Coil Load (Category AC-13) Make Contact: DC110V0.2
Rated Operating Current [A]: DC Coil Load (Category AC-13) Make Contact: DC220V0.1
Rated Operating Current [A]: DC Coil Load (Category AC-13) Break Contact: DC24V1
Rated Operating Current [A]: DC Coil Load (Category AC-13) Break Contact: DC110V0.2
Rated Operating Current [A]: DC Coil Load (Category AC-13) Break Contact: DC220V0.1
Conventional Free Air Thermal Current [A]5
Minimal Applicable Load20V 5mA
Contact Arrangements (Valid)1NO1NC
Function: Terminal CoversNo
Function: Wiring Streamlining TerminalNo
Independent MountingAvailable
Terminal Screw Size: Main Circuit (Power Side)M6
Terminal Screw Size: Main Circuit (Load Side)M6
Terminal Screw Size: Operating CircuitM4

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

TH-T65FS: frequently asked questions

When can TH-T65FS be shipped?

TH-T65FS is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up TH-T65FS in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for TH-T65FS and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for TH-T65FS, subject to availability and destination.
