800T/H Operators Parts
























Compare 800T/H Operators
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Illumination module input voltage | Operator cam code | Operator cap color | Operator function | Position 1 contact block |
|---|---|---|---|---|---|
| 800H-16JRG91KE7BX | 120V AC @ 50/60Hz | KE7 | Green | Spring return from left and right | 1-NCLB 1-NO standard contacts |
| 800H-16JRG91KC1AX | 120V AC @ 50/60Hz | KC1 | Green | Spring return from left and right | 1-NO 1-NC standard contacts |
| 800H-16JRG91KB7CX | 120V AC @ 50/60Hz | KB7 | Green | Spring return from left and right | 1-NCLB 1-NC standard contacts |
| 800H-16JRG91KB7AB | 120V AC @ 50/60Hz | KB7 | Green | Spring return from left and right | 1-NO 1-NC standard contacts |
| 800H-16JRG2KC7AX | 120V AC @ 50/60Hz | KC7 | Green | Maintained | 1-NO 1-NC standard contacts |
| 800H-24HRB5KL8AX | 24V AC/DC | KL8 | Blue | Spring return from right | 1-NO 1-NC standard contacts |
| 800H-24HRX2KB6AX | 24V AC/DC | KB6 | None (no knob) | Maintained | 1-NO 1-NC standard contacts |
| 800H-24HRX2KB6 | 24V AC/DC | KB6 | None (no knob) | Maintained | — |
| 800H-24JRB20KB7AX | 24V AC/DC | KB7 | Blue | Spring return from left and right | 1-NO 1-NC standard contacts |
| 800H-24JRA91KT1CX | 24V AC/DC | KT1 | Amber | Spring return from left and right | 1-NCLB 1-NC standard contacts |
| 800H-24JRA91KB7CX | 24V AC/DC | KB7 | Amber | Spring return from left and right | 1-NCLB 1-NC standard contacts |
| 800H-24HRR4KL8AX | 24V AC/DC | KL8 | Red | Spring return from left | 1-NO 1-NC standard contacts |
| 800H-24HRR2KB6BX | 24V AC/DC | KB6 | Red | Maintained | 1-NCLB 1-NO standard contacts |
| 800H-24HRR2KB6 | 24V AC/DC | KB6 | Red | Maintained | — |
| 800H-24HRA17KB6AX | 24V AC/DC | KB6 | Amber | Maintained | 1-NO 1-NC standard contacts |
| 800H-24HRC2KB6DX | 24V AC/DC | KB6 | Clear | Maintained | 1-NO standard contact |
| 800H-12HRR17KB6AX | 12V AC/DC | KB6 | Red | Maintained | 1-NO 1-NC standard contacts |
| 800H-12HRG2KB6AX | 12V AC/DC | KB6 | Green | Maintained | 1-NO 1-NC standard contacts |
| 800H-12JRG5KC7AX | 12V AC/DC | KC7 | Green | Spring return from right | 1-NO 1-NC standard contacts |
| 800H-12JRG5KB7CX | 12V AC/DC | KB7 | Green | Spring return from right | 1-NCLB 1-NC standard contacts |
| 800H-16HRG4KL8AX | 120V AC @ 50/60Hz | KL8 | Green | Spring return from left | 1-NO 1-NC standard contacts |
| 800H-16HRG2KB6NX | 120V AC @ 50/60Hz | KB6 | Green | Maintained | 2-NC standard contacts |
| 800H-16HRA2KB6DX | 120V AC @ 50/60Hz | KB6 | Amber | Maintained | 1-NO standard contact |
| 800H-16JRB4KB7AX | 120V AC @ 50/60Hz | KB7 | Blue | Spring return from left | 1-NO 1-NC standard contacts |
Common to all listed parts
| Lifecycle | Discontinued |
| Discontinued date | March 31, 2025 |
| Replacement category (Rockwell) | Functional Replacement |
| Repair options available | No |
| Enclosure compatibility (NEMA type) | 1, 4, 4X, 12, 13 |
| Hole diameter | 30.5 mm |
| Humidity | 50 % |
| Illumination lamp type | Incandescent |
