800T/H Operators Parts
























Compare 800T/H Operators
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Operator cap color | Operator cap type | Operator function | Illumination module input voltage | Illumination module termination wire range |
|---|---|---|---|---|---|
| 800HC-R7A | Blue | Booted head | Momentary contact | — | — |
| 800HC-QRB20B | Blue | Extended head without guard | Momentary contact | 240V AC/DC | 16 - 18 AWG (x2) |
| 800HC-QRB20 | No cap | Extended head without guard | Momentary contact | 240V AC/DC | 16 - 18 AWG (x2) |
| 800HC-QRB10R | Red | Extended head without guard | Momentary contact | 120V AC/DC | 14 - 18 AWG (x2) |
| 800HC-QRT10B | Blue | Fresnal | Push-to-test | 120V AC/DC | 14 - 18 AWG (x2) |
| 800HC-QRA10GD1 | Green | Extended head with guard | Momentary contact | 120V AC/DC | 14 - 18 AWG (x2) |
| 800H-QRA24GD2 | Green | Extended head with guard | Momentary contact | 24V AC/DC | 17 - 18 AWG (x2) |
| 800HC-JR5KA7B | Black with white Insert | Standard knob | Spring return from right | — | — |
| 800HC-PRA26W | White | Extended head with guard | Momentary contact | 240V AC @ 50/60Hz | 19 - 18 AWG (x2) |
| 800HC-PRA26G | Green | Extended head with guard | Momentary contact | 240V AC @ 50/60Hz | 19 - 18 AWG (x2) |
| 800HC-PRA16WA2 | White | Extended head with guard | Momentary contact | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) |
| 800HC-PRA16WD1 | White | Extended head with guard | Momentary contact | 120V AC @ 50/60Hz | 15 - 18 AWG (x2) |
| 800HC-UR35 | Black | Standard knob | Single turn | — | — |
| 800H-QRA10BD1 | Blue | Extended head with guard | Momentary contact | 120V AC/DC | 14 - 18 AWG (x2) |
| 800H-QRA10RA4 | Red | Extended head with guard | Momentary contact | 120V AC/DC | 14 - 18 AWG (x2) |
| 800H-QRA24RG1 | Red | Extended head with guard | Momentary contact | 24V AC/DC | 17 - 18 AWG (x2) |
| 800H-QRA10GA2 | Green | Extended head with guard | Momentary contact | 120V AC/DC | 14 - 18 AWG (x2) |
| 800H-QRA10GD2 | Green | Extended head with guard | Momentary contact | 120V AC/DC | 14 - 18 AWG (x2) |
| 800H-QRA12A | Amber | Extended head with guard | Momentary contact | 12V AC/DC | 14 - 18 AWG (x2) |
| 800H-QRA10C | Clear | Extended head with guard | Momentary contact | 120V AC/DC | 14 - 18 AWG (x2) |
| 800H-QRA12G | Green | Extended head with guard | Momentary contact | 12V AC/DC | 14 - 18 AWG (x2) |
| 800H-QRA20RD1 | Red | Extended head with guard | Momentary contact | 240V AC/DC | 16 - 18 AWG (x2) |
| 800H-QRA20 | No cap | Extended head with guard | Momentary contact | 240V AC/DC | 16 - 18 AWG (x2) |
Common to all listed parts
| Lifecycle | Discontinued |
| Discontinued date | March 31, 2025 |
| Repair options available | No |
| Enclosure compatibility (NEMA type) | 1, 4, 4X, 12, 13 |
| Hazardous location rating | false |
| Hole diameter | 30.5 mm |
| Humidity | 50 % |
| Operating temperature | -25 °C |
