Fan and blower Parts
Compare Fan and blower
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Catalog Number | Power Factor | Rated Efficiency | Product Net Weight | Dimension Diagram |
|---|---|---|---|---|---|
| ERM3007 | ERM3007 | 66 % | 73.40 % | 24 lb | 34LYK015 |
| YPC144A | YPC144A | 98 % | 67 % | 20 lb | 34LYM195 |
| ERL1319A277 | ERL1319A277 | 93 % | 84 % | 59 lb | 35LYF554 |
| YPC164A | YPC164A | — | 62 % | 20 lb | 34LYM195 |
| RL1310A | RL1310A | 70 % | 68 % | 34 lb | 35LYF391 |
| ERM3108 | ERM3108 | 78 % | 78.20 % | 31 lb | 34LY1237 |
| ERM3009 | ERM3009 | 78 % | 73.40 % | 24 lb | 34LYK015 |
| ERM3003 | ERM3003 | 62 % | 69.50 % | 21 lb | 34LYK015 |
| ERM3104 | ERM3104 | 66 % | 73.40 % | 24 lb | 34LYK019 |
| YPC245A | YPC245A | 96 % | 66 % | 21 lb | 34LYM197 |
| ERM3112 | ERM3112 | 74 % | 82.50 % | 38 lb | 35LYE411 |
| ERL1203A | ERL1203A | 89 % | 68.50 % | 20 lb | 34LYG752 |
| ERL1306A | ERL1306A | 95 % | 76.20 % | 26 lb | 34LYG867 |
| ERL1309A | ERL1309A | 99 % | 82 % | 36 lb | 35LYE4041 |
| RL1310A277 | RL1310A277 | — | 70 % | 42 lb | 35LYE410 |
| ERM3120 | ERM3120 | 83 % | 84 % | 34 lb | 35LYF883 |
| PSC3524A | PSC3524A | 81 % | 65 % | 24 lb | 34LYG144 |
| YPC264A | YPC264A | — | 66 % | 22 lb | 34LYM195 |
| YPC244A | YPC244A | 96 % | 66 % | 21 lb | 34LYM195 |
| ERM3115 | ERM3115 | 82 % | 77 % | 27 lb | 34LYM528 |
| ERM3111 | ERM3111 | 80 % | 76.80 % | 24 lb | 34LYK019 |
| ERM3010 | ERM3010 | 78 % | 78.20 % | 31 lb | 34LYK015 |
| ERM3116 | ERM3116 | 69 % | 85.50 % | 36 lb | 35LYE411 |
| RL1307A | RL1307A | 68 % | 68 % | 36 lb | 34LYG084 |
Common to all listed parts
| Brand / Label | Baldor-Reliance |
| Country or Territory of Origin | United States |
| Minimum Order Quantity | 1 piece |
| Order Multiple | 1 piece |
| Ambient Temperature | 40 °C |
| Number of Speeds | Single Speed |
| Type of Duty | Continuous |
| Starting of Motor | Direct On Line |
