Food Safe three phase motors Parts
Compare Food Safe three phase motors
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Catalog Number | Power Factor | Rated Efficiency | Product Net Weight | Dimension Diagram |
|---|---|---|---|---|---|
| VFSWDM3554-E | VFSWDM3554-E | 75 % | 86.50 % | 45 lb | 35LYE4649 |
| VFSWDM3711T-E | VFSWDM3711T-E | 94 % | 91.70 % | 149 lb | 37LYQ227 |
| CFSWDM3711T-E | CFSWDM3711T-E | 94 % | 91.70 % | 149 lb | 37LYQ242 |
| VFSWDNM3558-E | VFSWDNM3558-E | 78 % | 88.50 % | 63 lb | 35LYE4656 |
| VFSWDNM3555-E | VFSWDNM3555-E | 89 % | 88.50 % | 63 lb | 35LYE4656 |
| VFSWDNM3554-E | VFSWDNM3554-E | 77 % | 86.50 % | 59 lb | 35LYE4656 |
| CFSWDNM3611T-E | CFSWDNM3611T-E | 79 % | 89.50 % | 101 lb | 36LYR551 |
| CFSWDNM3610T-E | CFSWDNM3610T-E | 92 % | 89.50 % | 96 lb | 36LYR551 |
| CFSWDM3611T-5E | CFSWDM3611T-5E | 76 % | 89.50 % | 86 lb | 36LYR552 |
| VFSWDM3545-E | VFSWDM3545-E | 82 % | 82.50 % | 37 lb | 35LYE4656 |
| VFSWDM3546T-E | VFSWDM3546T-E | 66 % | 85.50 % | 37 lb | 35LYE4717 |
| CFSWDM3550-E | CFSWDM3550-E | 90 % | 85.50 % | 50 lb | 35LYE4735 |
| CFSWDM3538-E | CFSWDM3538-E | 65 % | 80 % | 38 lb | 35LYE4735 |
| CFSWDM3558-E | CFSWDM3558-E | 81 % | 86.50 % | 45 lb | 35LYE4741 |
| FSWDM3546T-E | FSWDM3546T-E | 66 % | 85.50 % | 41 lb | 35LYE4928 |
| VFSWDM3550T-E | VFSWDM3550T-E | 90 % | 85.50 % | 50 lb | 35LYE4717 |
| VFSFWDM3542-E | VFSFWDM3542-E | 65 % | 84 % | 37 lb | 35LYE4649 |
| VFSFWDM3546-E | VFSFWDM3546-E | 66 % | 85.50 % | 44 lb | 35LYE4649 |
| CFSWDM3550T-E | CFSWDM3550T-E | 90 % | 85.50 % | 50 lb | 35LYE4742 |
| CFSWDM3555T-E | CFSWDM3555T-E | 85 % | 86.50 % | 50 lb | 35LYE4743 |
| CFSWDM3615T-E | CFSWDM3615T-E | 81 % | 89.50 % | 101 lb | 36LYR552 |
| CFSWDM3555-E | CFSWDM3555-E | 85 % | 86.50 % | 50 lb | 35LYE4741 |
| CFSWDM3545-E | CFSWDM3545-E | 82 % | 82.50 % | 38 lb | 35LYE4735 |
| CFSWDM3559T-5E | CFSWDM3559T-5E | 91 % | 86.50 % | 61 lb | 35LYE4743 |
Common to all listed parts
| Brand / Label | Baldor-Reliance |
| Country or Territory of Origin | United States |
| Minimum Order Quantity | 1 piece |
| Order Multiple | 1 piece |
| Ambient Temperature | 40 °C |
| Duty Time | 60 Min |
| Insulation Class | H |
| Number of Phases | 3-phase |
