LV HRC Design Parts
Compare LV HRC Design
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | design of the product | power loss [W] | power loss [W] — for rated value of the current at AC in hot operating state per pole | power loss [W] — maximum | Net Weight |
|---|---|---|---|---|---|
| 3NC3241-1U | With slotted blade contacts | 155 W | 155 W | 155 W | 811 g |
| 3NC3240-6U | With female thread on both sides | 140 W | 140 W | 140 W | 741 g |
| 3NC3240-1U | With slotted blade contacts | 145 W | 145 W | 145 W | 808 g |
| 3NC3238-6U | With female thread on both sides | 135 W | 135 W | 135 W | 723 g |
| 3NC3238-1U | With slotted blade contacts | 135 W | 135 W | 135 W | 811 g |
| 3NC3237-6U | With female thread on both sides | 130 W | 130 W | 130 W | 787 g |
Common to all listed parts
| product designation | SITOR fuse link |
| design of an identification indicator | front indicator |
| design of the fuse link | SITOR, LV HRC design |
| size of fuse system according to EN 60269-1 | NH3 |
| operating class of the fuse link | aR |
| type of voltage of the operating voltage | AC/DC |
| operating voltage at AC according to UL rated value | 690 V |
| supply voltage — at AC | 690 V |
