Siemens 3NC3238-6U

SITOR fuse link, with female thread on both sides, NH3, In: 800 A, aR, Un AC: 690 V, Un DC: 440 V

MPN
3NC3238-6U
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Siemens parts? We buy surplus →

What is the Siemens 3NC3238-6U?

SITOR fuse link, with female thread on both sides, NH3, In: 800 A, aR, Un AC: 690 V, Un DC: 440 V, front indicator

Specifications

Model

product brand nameSENTRON
product designationSITOR fuse link
design of the productWith female thread on both sides
design of an identification indicatorfront indicator
design of the switching contactwith M12 female thread at both ends for direct busbar mounting
design of the fuse linkSITOR, LV HRC design

General technical data

size of fuse system according to EN 60269-1NH3
operating class of the fuse linkaR
varying load factor (WL)0.95
type of voltage of the operating voltageAC/DC
operating voltage at AC according to UL rated value690 V

Supply voltage

supply voltage — at AC690 V
supply voltage — at DC440 V

Breaking Capacity

switching capacity current — according to IEC 60947-2 rated value120 kA

Dissipation

power loss [W]135 W
power loss [W] — for rated value of the current at AC in hot operating state per pole135 W
power loss [W] — maximum135 W

Product details

product descriptionwith female thread on both sides, silver-plated
accessories includedno

Mechanical Design

mounting positionAny, preferably vertical
Net Weight723 g

Environmental conditions

ambient temperature during operation — minimum-20 °C
ambient temperature during operation — maximum50 °C
environmental category-20 to +50 at 95% relative humidity

Downloads & documentation

Official documents from Siemens, downloaded directly from the manufacturer.

Data sheets & manuals

3NC3238-6U: frequently asked questions

When can 3NC3238-6U be shipped?

3NC3238-6U is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 3NC3238-6U in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 3NC3238-6U and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3NC3238-6U, subject to availability and destination.
