Stepping motors for Small Modules SMS Parts
Compare Stepping motors for Small Modules SMS
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | SMS size | Length L [mm] | Width [mm] | Height [mm] | Rated current [A] |
|---|---|---|---|---|---|
| R348707101 | 80 | 106.0 | 85.0 | 156.0 | 5.5 |
| R348707001 | 40 | 65.0 | 56.4 | 106.0 | 3 |
| R348706901 | 30 | 61.0 | 42.2 | 100.0 | 2 |
Common to all listed parts
| Operating temperature (min. … max.) | +5 °C ... +40 °C |
| Protective functions | Overcurrent, overvoltage/undervoltage, overtemperature |
| Mode of operation | Position/speed or torque setpoint |
| Fieldbus interface | EtherCAT |
| Motor encoder | Incremental, magnetic, 4096 PPR |
| Insulation class | B |
| Maximum operating temperature [°C] | +40 |
| Minimum operating temperature [°C] | +5 |
