Roller guide rails Parts
Compare Roller guide rails
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Nominal size [mm] | Material (profiled rail systems) | Accuracy class | Guide rail cover | Number of sections |
|---|---|---|---|---|---|
| R184527344 | 25 | Hard chrome plated | H - Highly accurate | Without cover strip | 4-piece |
| R184527343 | 25 | Hard chrome plated | H - Highly accurate | Without cover strip | 3-piece |
| R184527342 | 25 | Hard chrome plated | H - Highly accurate | Without cover strip | 2-piece |
| R184527341 | 25 | Hard chrome plated | H - Highly accurate | Without cover strip | 1-piece |
| R183536168 | 125 | Carbon steel | SP - Super precise | With cover strip | 8-piece |
| R183536167 | 125 | Carbon steel | SP - Super precise | With cover strip | 7-piece |
| R183536166 | 125 | Carbon steel | SP - Super precise | With cover strip | 6-piece |
| R183536165 | 125 | Carbon steel | SP - Super precise | With cover strip | 5-piece |
| R183536164 | 125 | Carbon steel | SP - Super precise | With cover strip | 4-piece |
| R183536163 | 125 | Carbon steel | SP - Super precise | With cover strip | 3-piece |
| R183536162 | 125 | Carbon steel | SP - Super precise | With cover strip | 2-piece |
| R183536161 | 125 | Carbon steel | SP - Super precise | With cover strip | 1-piece |
| R183536268 | 125 | Carbon steel | P - Precise | With cover strip | 8-piece |
| R183536267 | 125 | Carbon steel | P - Precise | With cover strip | 7-piece |
| R183536266 | 125 | Carbon steel | P - Precise | With cover strip | 6-piece |
| R183536265 | 125 | Carbon steel | P - Precise | With cover strip | 5-piece |
| R183536264 | 125 | Carbon steel | P - Precise | With cover strip | 4-piece |
| R183536263 | 125 | Carbon steel | P - Precise | With cover strip | 3-piece |
| R183536262 | 125 | Carbon steel | P - Precise | With cover strip | 2-piece |
| R183536261 | 125 | Carbon steel | P - Precise | With cover strip | 1-piece |
| R183536368 | 125 | Carbon steel | H - Highly accurate | With cover strip | 8-piece |
| R183536367 | 125 | Carbon steel | H - Highly accurate | With cover strip | 7-piece |
| R183536366 | 125 | Carbon steel | H - Highly accurate | With cover strip | 6-piece |
| R183536365 | 125 | Carbon steel | H - Highly accurate | With cover strip | 5-piece |
Common to all listed parts
| Version | Roller rail systems |
| Format | SNS - Standard guide rail |
| Guide rail mounting | For bolting from above |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Weight [kg] | 0 |
| Footnote of H2 with cover strip (profiled rail systems) | With cover strip 0.3 mm |
| Dimension N6 tolerance (profiled rail systems) [mm] | ±0.5 |
