High precision ball guide rail BSHP Parts
Compare High precision ball guide rail BSHP
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Accuracy class | Guide rail mounting | Guide rail cover | Minimum length Lmin [mm] | Number of sections |
|---|---|---|---|---|---|
| R167635236 | P - Precise | For bolting from above | With steel caps | 112.0 | 6-piece |
| R167635235 | P - Precise | For bolting from above | With steel caps | 112.0 | 5-piece |
| R167635234 | P - Precise | For bolting from above | With steel caps | 112.0 | 4-piece |
| R167635233 | P - Precise | For bolting from above | With steel caps | 112.0 | 3-piece |
| R167635232 | P - Precise | For bolting from above | With steel caps | 112.0 | 2-piece |
| R167635231 | P - Precise | For bolting from above | With steel caps | 112.0 | 1-piece |
| R167530238 | P - Precise | For bolting from above | Plastic caps | 104.0 | 8-piece |
| R167530237 | P - Precise | For bolting from above | Plastic caps | 104.0 | 7-piece |
| R167530236 | P - Precise | For bolting from above | Plastic caps | 104.0 | 6-piece |
| R167530235 | P - Precise | For bolting from above | Plastic caps | 104.0 | 5-piece |
| R167530234 | P - Precise | For bolting from above | Plastic caps | 104.0 | 4-piece |
| R167530233 | P - Precise | For bolting from above | Plastic caps | 104.0 | 3-piece |
| R167530232 | P - Precise | For bolting from above | Plastic caps | 104.0 | 2-piece |
| R167530231 | P - Precise | For bolting from above | Plastic caps | 104.0 | 1-piece |
| R167730438 | N - Normal | For bolting from below | Without cover strip | 104.0 | 8-piece |
| R167730437 | N - Normal | For bolting from below | Without cover strip | 104.0 | 7-piece |
| R167730436 | N - Normal | For bolting from below | Without cover strip | 104.0 | 6-piece |
| R167730435 | N - Normal | For bolting from below | Without cover strip | 104.0 | 5-piece |
| R167730434 | N - Normal | For bolting from below | Without cover strip | 104.0 | 4-piece |
| R167730433 | N - Normal | For bolting from below | Without cover strip | 104.0 | 3-piece |
| R167730432 | N - Normal | For bolting from below | Without cover strip | 104.0 | 2-piece |
| R167730431 | N - Normal | For bolting from below | Without cover strip | 104.0 | 1-piece |
| R167635438 | N - Normal | For bolting from above | With steel caps | 112.0 | 8-piece |
| R167635437 | N - Normal | For bolting from above | With steel caps | 112.0 | 7-piece |
Common to all listed parts
| Version | Ball rail system |
| Nominal size [mm] | 35/90 |
| Format | BNS - wide guide rail |
| Material (profiled rail systems) | Carbon steel |
| Max. length Lmax [mm] | 3836.0 |
| Number of holes nB (profiled rail systems) | 48 |
| Mass m (kg/m) [kg/m] | 21 |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
