Delta Parts
Compare Delta
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Prot. rating, in-line wrist (IEC 60529) | A4 |
|---|---|---|
| U8124591 | IP69K | 840 °/s |
| U8124592 | IP69K | 840 °/s |
| U810110562 | IP67 | 1091 °/s |
| U8124603 | IP69K | 840 °/s |
| U8124602 | IP69K | 840 °/s |
| U8167335 | IP69K | 840 °/s |
| U8167334 | IP69K | 840 °/s |
Common to all listed parts
| Maximum payload | 6 kg |
| Rated payload | 3 kg |
| Maximum reach | 1200 mm |
| Mounting position | Ceiling |
| Pose repeatability (ISO 9283) | 0.05 mm |
| Number of axes | 4 |
| Ambient temperature during operation | 0 °C to 45 °C (273 K to 318 K) |
| Ambient temperature during stor./transp. | -25 °C to 55 °C (248 K to 328 K) |
