Temperature modules Parts

B&R

I/O module, 4 inputs for Pt100 or resistance measurement

B&R

I/O module, 4 inputs for KTY10-6, KTY84-130

B&R

I/O module, 4 inputs for thermocouple sensors

Compare Temperature modules

Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.

MPN	Power consumption – Internal I/O	Input filter – Cutoff frequency	Output format	Sensor standard	Common-mode range
X67AT1311	1.5 W	115 Hz / First-order filter	INT or UINT for resistance measurement	EN 60751	±1 VDC
X67AT1322	1.5 W	115 Hz / First-order filter	INT or UINT for resistance measurement	EN 60751	±1 VDC
X67AT1402	2.6 W	4 Hz / First-order filter	INT	IEC 60584-1	±12 VDC

Diagnostics – Inputs	Yes, using LED status indicator and software
Diagnostics – I/O power supply	Yes, using LED status indicator and software
Connection type – X2X Link	M12, B-coded
Connection type – Inputs	4x M12, A-coded
Connection type – I/O power supply	M8, 4-pin
Power consumption – X2X Link power supply	0.75 W
Certifications – CE	Yes
Certifications – UKCA	Yes
