Siemens 8PQ5000-5BA24
Separation rear, 2 x ACB main busbar: double W: 1000 mm D: 800/1200 mm
- MPN
- 8PQ5000-5BA24
- Category
- Main busbar rear
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Siemens 8PQ5000-5BA24?
Separation rear, 2 x ACB main busbar: double W: 1000 mm D: 800/1200 mm
Specifications
Model
| product brand name | SIVACON S4 |
| product designation | separation |
| design of the surface | zinc plated |
General technical data
| design | assembly kit |
| suitability for use | for 3WA air circuit breakers |
| color | miscellaneous |
Product details
| product component — cable entry | No |
| product component — lock | No |
Mechanical Design
| width | 1 000 mm |
| installation width for cabinet installation | 1 000 mm |
| shape of inner subdivisions — shape 2a | Yes |
| shape of inner subdivisions — shape 2b | Yes |
| shape of inner subdivisions — shape 3a | Yes |
| shape of inner subdivisions — shape 3b | Yes |
| shape of inner subdivisions — shape 4a | Yes |
| shape of inner subdivisions — shape 4b | Yes |
| Net Weight | 19.36 kg |
| material | sheet-steel |
Certificates
| reference code according to IEC 81346-2 | UC |
