Siemens 8GK2124-3KK23

ALPHA 630 UNIVERSAL, wall-mounted cabinet, IP55, Protection class 1, H: 1000 mm, W: 600 mm, T: 250 mm

MPN: 8GK2124-3KK23
Category: Unequipped distribution boards

Price and lead time confirmed within 1 business day

Request a Quote

1We check stock, condition and lead time
2You get a written quote by email
3Approve it and we ship — in-stock parts within 1 business day

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
100% positive eBay feedback
Ships via

Have spare Siemens parts? We buy surplus →

What is the Siemens 8GK2124-3KK23?

ALPHA 630 UNIVERSAL, wall-mounted cabinet, IP55, Protection class 1, H: 1000 mm, W: 600 mm, T: 250 mm, RAL 7035, without door

Specifications

Model

product brand name	ALPHA
product designation	Wall-mounted cabinet
design of the product	Without door
surface processing	powder-coated

Protection class

protection class IP	IP55
operating resource protection class	Safety class 1
IK protection class	IK09
suitability for interaction lightning protection	Yes
suitability for use for outside use	No

Appearance

RAL color number	7 035
product component — cable entry	Yes
product component — mounting plate	No
special product feature	Without door
product extension optional side-by-side mounting	Yes
number of rows	5

Mechanical Design

height	1 000 mm
width	600 mm
depth	250 mm
installation depth	250 mm
number of modular width units	120
fastening method	surface mounting
Net Weight	20 kg
material of the enclosure	Steel

Downloads & documentation

Official documents from Siemens, downloaded directly from the manufacturer.

Data sheets & manuals

Product data sheet 8GK2124-3KK23PDF
