Siemens 7PA2221-1
FAST LOCK-OUT RELAY 8 CHANGE OVER CONTACTS OPERATING TIME 10MS AUXILIARY VOLTAGE: 60V DC WITH RESET…
- MPN
- 7PA2221-1
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Siemens 7PA2221-1?
FAST LOCK-OUT RELAY 8 CHANGE OVER CONTACTS OPERATING TIME 10MS AUXILIARY VOLTAGE: 60V DC WITH RESET PUSHBUTTON WITH FLUSH MOUNTING SOCKET 7XP9010-1
Specifications
General technical data
| type of voltage | DC |
| continuous current | 10 A |
| switching behavior | bistable |
| type of switching contact | bifurcated contact |
| design of the switching function / positively driven | Yes |
| response time | 10 ms |
Product details
| product component / LED | No |
Product Functions
| manual RESET | Yes |
Supply voltage
| supply voltage / at DC / rated value | 60 V |
Inputs / Outputs
| number of NC contacts | 0 |
| number of NO contacts | 0 |
| number of CO contacts | 8 |
| switching capacity active power / at DC / maximum | 4 400 W |
| switching capacity active power / at DC / maximum / note | at 110V DC |
Mechanical Design
| width | 120 mm |
| height | 80 mm |
| depth | 146.5 mm |
| type of electrical connection | screw terminal |
| product feature / plug-in terminal blocks | No |
| design of the snap-on socket base | flush-mounting socket |
Degree of protection / protection class
| protection class IP / on the front | IP40 |
| protection class IP / rear side | IP10 |
Environmental conditions
| ambient temperature / during operation | -40 ... +70 °C |
