Siemens 7KE9000-3PA02-8AA0

SICAM PAS - Option 2 PQ applications; download software, documentation and license(s) for download

MPN: 7KE9000-3PA02-8AA0
Category: Options

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Siemens parts? We buy surplus →

What is the Siemens 7KE9000-3PA02-8AA0?

SICAM PAS - Option 2 PQ applications; download software, documentation and license(s) for download. Consignee e-mail address required for delivery. note: this MLFB and its ALM licenses cannot be used for the extension of dongle/ soft license-licensed installations

Specifications

General technical data

target system	SICAM PQS / PAS
national language / of the software	German / English

Product details

product description

power quality software

Model

product designation

SICAM PQS - option

Power Quality functions

power quality assessment function / PQ Grid Code Evaluation according to EN 50160	Yes
power quality assessment function / PQ Grid Code Evaluation according to IEC/TS 62749	Yes
power quality assessment function / PQ Grid Code Evaluation according to IEC 61000-2-4	Yes
power quality assessment function / PQ Grid Code Evaluation with regard to customized PQ grid codes	Yes
power quality assessment function / detecting and visualization of voltage fluctuations	Yes
power quality assessment function / evaluation of line frequency	Yes
power quality assessment function / evaluation of voltage of harmonic component	Yes
power quality assessment function / evaluation of the voltage unbalance / according to IEC 61000-4-30, Class S	Yes
power quality assessment function / evaluation of flickering	Yes
power quality assessment function / evaluation of voltage events	Yes
power quality assessment function / evaluation of PQ status and PQ index	Yes

Product Functions

user interface info texts can be translated into any national language	Yes
Unicode support for process data	Yes
querying and storing of fault records via FTP	Yes
detection of cause of malfunction	Yes
local storage of the PQDIF files	Yes
automatic report recording	Yes
scheduled reports	Yes
evaluation of fault records	Yes
fault location (with regard to fault records)	Yes
automatic data export from COMTRADE files (fault records)	Yes
automatic data export from reports	Yes
notification via SMS/email	Yes

Requirements

design of the drive/storage medium / required / DVD drive	No
operating system / usable / Windows 7	Yes
operating system / usable / Windows 10	Yes
operating system / usable / Windows 2012 Server	Yes
operating system / usable / Windows 2016 Server	Yes
operating system / usable / Windows Server 2019	Yes
processor clock frequency / minimum	2 GHz
storage capacity / on hard disk / required	100 Gbyte
storage capacity / of the main memory or RAM / minimum	16 Gbyte
product function / firmware identifier	Yes

Downloads & documentation

Official documents from Siemens, downloaded directly from the manufacturer.

Data sheets & manuals

Product data sheet 7KE9000-3PA02-8AA0PDF

7KE9000-3PA02-8AA0: frequently asked questions

When can 7KE9000-3PA02-8AA0 be shipped?

7KE9000-3PA02-8AA0 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 7KE9000-3PA02-8AA0 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 7KE9000-3PA02-8AA0 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 7KE9000-3PA02-8AA0, subject to availability and destination.
